SQU OF80 Universal Car Emulator Car Emulator Signal Reset Immo off Seat occupancy sensor/Tacho programs Diagnostic Tool

Description of OF80

Features

1. The LED behavior

-no jumpers-diagnostic mode-it flashes every second

-adjusting to the ecu-flashing 0, 1 sec

-after adjusting it lights constantly and blinks every other second

2. Tachometer tester programs

You can use it to tum on the instrument cluster on the table in order to diagnose faults. After

connecting the emulator to instrument cluster, most of instrument cluster segments are displayed

making it easier to locate damaged areas.

3. This emulator is reusable, Tested on tacho—for Audi Q7 and for A6, for Citroen C4 Picasso, for EMF Display, for Renault Kangoo 3 Display, for Renault Scenic II, for Espace IV Tacho, for Renault Scenic II Full, for Renault Scenic III+ Navi, for VW Passat B6

Immo Programs

1. VAG4-V1

2. VAG4-V2

3. For WV BYPASS GOLD immo OFF

4. For WV automatic immo ON

5. For WV without CAN

6. For WV Hitachi

7. For WV -valve Code

8. For WV EDC15 immo OFF

9. For WV EDC15 immo ON

10. For WV EDC16 K-line Immo OFF

11. For WV EDC16 K-line Immo ON

12. For WV EDC16 CAN 1.9 / 2.0 OFF

13. For WV EDC16 CAN 1.9 / 2.0 ON

14. For WV EDC16 CAN 2.7 / 3.0 OFF

15. For WV EDC16 CAN 2.7 / 3.0 ON

16. For WV ME7 immo OFF

17. For WV ME7 immo ON

18. For BMW EWS 2/3

19. For BMW EWS 2/3 (use ISN)

20. For Chrysler

21. For Citroen, For Peugeot CAN

22. For Citroen, For Peugeot CAN V1

23. For Citroen, For Peugeot CAN V2

24. For Citroen, For Peugeot CAN (use pin) v1

25. For Citroen, For Peugeot CAN (use pin) v2

26. For Daewoo1

27. For Daewoo2

28. For Fiat without CAN

29. For Fiat with CAN-5SF/6F3 ECU

30. For FSO Polonez

31. For Honda

32. For Kia Sportage 2. OTD

33. For Mazda with 93C56

34. For Mercedes CR without CAN

35. For Mercedes CR1 with CAN WSP

36. For Mercedes CR1 with CAN EZ

37. For Mercedes CRl with CAN infrared

38. For Mercedes CR2 with CAN WSP

39. For Mercedes ESL

40. For Mercedes ESL 2

41. For Nissan NATS4/5

42. For Opel immo with HCO5

43. For Renault with CAN -ver 1

44. For Renault with CAN -ver 2

45. For Renault without CAN

46. For Renault without CAN old ECU

47. For Suzuki with X24C01 memory

48. For Suzuki with OKI memory

49. For Suzuki with 93C56 memory

50. For TMS374-For citroen, For Peugeot, For Renault

51. For Yamaha

Seat Occupancy Sensor Programs

1.
For BMW: 2007 to 2010
Europe: E60, E63, E64, E65, E70, E71, E81, E90, E92, E93

2 For BMW: 1997 to 2007 Models from 1997 to 2003-e31 E36 E38, E39, E46, E53 Tachom er tester programs Models from 2003 to 2007-e60 E63 E65, E87 EO

3.
For BMW: 1997 to 2007 Models from 1997 to 2003-e31 E36 E38, E39. E46 E53 Models from 2003 to 2007. E40 E43. E65, E87 E90

4.
For Benz: E-class W211(2002-2004)with controller airbag Temic, s-class W220(2003-2005)

5.
For Benz: E-class W211(2002-2004)with controller airbag Temic, s-class W220(2003-2005)

6.
For Benz: A-class W168 (1997-2001), c-class ML with controller airbag TRW 1999, e-class W210 to 1999, e-class before lifting indicator Airbag OFF

7.
For Benz: A-class W168(1997-2001)c-class w202(1999-2001), Vito W638 to 2003, ML with controller airbag TRW 1999, e-class W210 to 1999, e-class before lifting indicator Airbag OFF

8.
For Benz: E-class W210(2000-2003)with indicator Airbag OFF, Vito W639(2002-2005), ML W163 as of 2000, a-class W168(2002-2005), S-class W220(2000-2003), c-class W203 to 2005 CLK W209, Vaneo

9.
For Benz: E-class W210(2000-2003)with indicator Airbag OFF, Vito W639(2002-2005)ML W163 as of 2000, a-class W dass W220(2000-2003), c-class W203 to 2005 CLK W209, Vaneo

10. For Mini Cooper 2002-2005 v1

11. For Mini Cooper 2002-2005 v2

12.
For Mazda: Premacy, mx-5, 626, 323, 6 v1

13.
For Mazda: Premacy, mx-5, 626, 323, 6 v2

14.
For Fiat: stilo V1

15.
For Fiat: Stilo V2

16.
For Mercedes: e-class w211 from 2004 to 2007 Temic, SL W230 models year 2004 only. SLK W171 from 2004 to 2011

17.
For Mercedes: e-class W211 from 2003 to 2007, For Bosch contoller c-class W203 from 2006 to 2007 CLS W219 from 2005 to 2010. CLK W209 from 2006 to 2009, s-class W220 from 2002 to 2005, S- dass W221 year 2006 only

18.
For Mercedes: e-class W211 from 2002 to 2003 with airbag
ECUS: For Temic 002 820 35 26 Bosch 002 82029260285001 441

19.
For Opel V1: Corsa C and Vectra C

20.
For Opel V2: Astra G, Meriva A, Omega B FL Signum and Zafira A

21.
For Ford: Mondeo 2001-2003

Tacho Programs

1. For Audi Q7 and A6

2. For Citroen C4 Picasso

3. For EMF Display

4. For Renault Kangoo 3 Display

5. For Renault Scenc II, Espace IV Tacho

6. For Renault Scenic Full

7. For Renault Scenic III+ Navi

8. For WV Passat B6

Description of Universal

Features

1. For WV automatic immo OFF

Programs no. 1 and 2 enable the emulator to automatically remove immo from a car by identifying ECU type and selecting a relevant program.
Attention! Selection of programs no. 1 and 2 eliminates the possibility to use the remainder of the programs from 6 to 15.

2. For WV automatic immo ON

Programs no. 1 and 2 enable the emulator to automatically remove immo from a car by identifying ECU type and selecting a relevant program.
Attention! Selection of programs no. 1 and 2 eliminates the possibility to use the remainder of the programs from 6 to 15.

3. For WV without CAN

forAudi, forSeat, forSkoda, forVolkswagen
W1 and W2 systems up to around 2001. EDC15 and 5-socket LT28/LT35 ECUs – when the chassis numbers are not entered – even up to
2006. Diesel and petrol Ford cars with VW systems (the VW symbol is visible on the ECU).

4. For WV – For Hitachi

forAudi, forSeat, forSkoda, forVolkswagen
It is suitable for VAG group cars with Hitachi ECU to about 1997.

5. For WV – Valve Code

forAudi, forSeat, forSkoda, forVolkswagen
To unlock the valve code on injection pump in vehicles VW 1.9 Diesel.

6. For WV EDC15 immo OFF (single use) for Audi, for Seat, for Skoda, for
Volkswagen Use:

Engine capacity: 1.2, 1.4, 1.9, 2.5 with W2 and W3 systems, diesel engines from 2000 to 2004, some to 2006, and even 2008 (except Audi with coded pump)
Suitable for vehicles with 2-socket ECUs.

7. For WV EDC15 immo ON (single use) for Audi, for Seat, for Skoda, for
Volkswagen Use:

Engine capacity: 1.2, 1.4, 1.9, 2.5 with W2 and W3 systems, diesel engines from 2000 to 2004, some to 2006, and even 2008 (except Audi with coded pump)
Suitable for vehicles with 2-socket ECUs.

8. For WV EDC16 K-LINE immo OFF (single use) for Audi, for Seat, for Skoda, for
Volkswagen Use:

Suitable for vehicles with 2-socket ECUs
0 281 011 XXX
0 281 012 XXX
0 281 013 XXX
0 281 014 XXX
0 281 015 XXX
Engine capacity: 1.9 TDI 2.0 TDI 2.5 TDI

9. For WV EDC16 K-LINE immo ON (single use) for Audi, for Seat, for Skoda, for
Volkswagen Use:

Suitable for vehicles with 2-socket ECUs
0 281 011 XXX
0 281 012 XXX
0 281 013 XXX
0 281 014 XXX
0 281 015 XXX
Engine capacity: 1.9 TDI 2.0 TDI 2.5 TDI

10. For WV EDC16 with CAN 1.9 2.0 TDI immo OFF (single use) for Audi, for Seat, for Skoda, for Volkswagen

Use: Suitable for vehicles with 2-socket ECUs 0 281 012 XXX

11. For WV EDC16 with CAN 1.9 2.0 TDI immo ON (single use) for Audi, for Seat, for Skoda, for Volkswagen

Use: Suitable for vehicles with 2-socket ECUs 0 281 012 XXX

12. For WV EDC16 with CAN 2.7 3.0 TDI immo OFF (single use) for Audi, for Seat, for Skoda, for Volkswagen

Use: Suitable for vehicles with 2-socket ECUs
0 281 012 XXX
0 281 013 XXX
0 281 014 XXX

13. For WV EDC16 with CAN 2.7 3.0 TDI immo ON (single use) for Audi, for Seat, for Skoda, for Volkswagen
Use: Suitable for vehicles with 2-socket ECUs
0 281 012 XXX
0 281 013 XXX
0 281 014 XXX

14. For WV ME7 immo OFF (single use) for Audi, for Seat, for Skoda, for Volkswagen

Use: Suitable for vehicles with ME7 for Bosch ECUs
Engine capacity: 1.4 1.8 2.0 2.4 2.6 2.8 3.0 3.5 4.2
Production year: from 1999 to 2008

15. For WV ME7 immo ON (single use) for Audi, for Seat, for Skoda, for Volkswagen

Use: Suitable for vehicles with ME7 for Bosch ECUs
Engine capacity: 1.4 1.8 2.0 2.4 2.6 2.8 3.0 3.5 4.2
Production year: from 1999 to 2008

16. For Chrysler

Use:
– for Chrysler Voyager 2.5TD 1999-2001
– for Dodge Caravan 2.5TD 1999-2001
– for Jeep Cherokee 2.5TD 1999-2001

17. For Citroen, for Peugeot with CAN

Use: EDC16 1.4 1.6 HDI with CAN
EDC15 HDI with CAN

18. For Daewoo 1

Use:
ECU with 2 white – red sockets
ECU with a blue socket

19. For Daewoo 2

Use:
Matiz SIEMENS, KEMSCO ECU
Tacuma KEMSCO ECU
Lanos 1.4 OHC hybrid ECU
Kalos SIRIUS D42 1.2 ECU
for Chevrolet Aveo 4R ECU 1.2 8V

20. For Fiat without CAN

Use:
for Fiat, for Citroen, for Peugeot diesel without CAN 2-socket ECU
for Alfa, for Lancia, for Fiat 1.9 Jtd 2.4 Jtd 5-socket ECU
for IAW49F Fiat Bravo 1.6 16V
for IAW 4AF Fiat Seicento, Panda 1.1 8V
for Lancia Kappa 2.0 i 16V Turbo 0 261 203 792
for Lancia Kappa 2.0 i 20V 0 261 203 670
for Lancia Kappa 2.4 i 16V 0 261 203
for Lancia Kappa 3.0 i 24V 0 261 203 482

21. For Fiat with CAN

ECU 5SF and 6F3

22. For Honda

Use: for Honda Accord, for CRV, for Civic and other (production year 1999-2002)

23. For Kia Sportage 2.0TD

for Kia Sportage 2.0 TD ECU ZEXEL immo with remote control

24. For Mercedes CR without CAN Infrared

Use: INFRARED IMMO
12-pin module + 2-pin CAN but only L connected (there is no CAN H) green and red LEDs flash in the mirror.
2.2 Diesel 1-socket Lucas
1.8 2.0 2.3 petrol hybrid SIEMENS ECU
2.0 petrol hybrid BOSCH ECU

25. For Mercedes CR1 with CAN WSP

Vito 2.2 Cdi 5-socket ECU
A-class 1.7 Cdi 5-socket ECU
EDC 1-socket ECU
2.5TD 2.9TD 3.0TD with mechanical and electronic ignition switch
for Bosch ECU with HC11E9
E-class 4- socket Lucas with mechanical and electronic ignition switch
A-Class VDO MSM ECU
1.4 1.6 1.9 gasoline

26. For Mercedes CR1 with CAN EZS

2-socket (white) VDO ECU with 24c02 memory

27. For Mercedes CR1 with CAN infrared

2-socket (black) VDO ECU with X24C01 memory
2-socket (yellow) VDO ECU with X24C02 memory
for 2-socket B–osch ECU with B58 (24LC02) memory

28. For Mercedes CR2 with CAN WSP

Sprinter 2.2 Cdi 2.7 Cdi
ML 2.7 Cdi 5 plugs – it starts automatically
it also works in 2.7 and 3.2 with electronic ignition switch it starts automatically.

29. For Mercedes ESL – steering wheel column lock emulator.

The emulator works with Mercedes electronic ignition switch in older models (W202, W208, W210)and allows to check newer models (W203, W209, W211, Vito 639).
The emulator can also be used to verify the original electronic ignition switch and steering column lock.

30. For Mercedes ESL2 – steering wheel column lock emulator.

The emulator works with Mercedes electronic ignition switch in W906 (Sprinter II, VW Crafter), W639, W211, W209, W202, W208, W210
Works with ignition switchs numbered:
A 906 545 64 08
639 545 05 08
208 545 00 08
208 545 01 08
208 545 02 08
208 545 03 08
210 545 00 08
210 545 01 08
210 545 02 08
210 545 03 08
31. For Nissan NATS 4 and 5

ECU from 2000 to 2002 – NATS 4 and 5 immo
2.2 2.7 diesel 5-socket ECU with 24C04 memory
1.5 gasoline Hitachi MEC with 93C46 and 93C56 memory
1.8 and 2.0 gasoline Hitachi MEC with 93C56 memory
Models: Almera, Almera Tino, Primera, Terrano

32. For Opel immo with HC05

1.2, 1.4 petrol 2-socket (black) ECU with Motorola HC11E20 processor
2.0, 2.2 and 2.5 petrol ECU with 24C02 eeprom memory

33. For Renault with CAN

SIRIUS 32 with CAN
SIRIUS 34 with CAN – NEW!!!
3-socket DELPHI with CAN – 95080 memory
3-socket BOSCH EDC15 with CAN – 5P08C3 memory
EMS 3132 with CAN NEW!!!
EMS 3134 with CAN NEW!!!

34. For Renault without CAN

Syrius 32 without CAN
Syrius 34 1.4 1.6 2.0
EMS 3132
1.9 2.2 and 2.5 DCI without CAN
1.5 DCI without CAN
1.9 DTI 1-socket ECU
1.9 DTI 2-socket ECU
1.9 Diesel DCU3
2.8 TD
3.0 gasoline 1-socket ECU

35. For Renault without CAN old ECUs

for Syrius 32 without CAN
for Syrius 34 1.4 1.6 2.0
EMS 3132
1.9 2.2 and 2.5 DCI without CAN
1.5 DCI without CAN
1.9 DTI 1-socket ECU
1.9 DTI 2-socket ECU
1.9 Diesel DCU3
2.8 TD
3.0 gasoline 1-socket ECU

36. For Suzuki with X24C01 memory

Engine Control Module with memory X24C01
37. For Suzuki with OKI memory

Engine Control Module with memory OKI

38. For Suzuki 93C56 memory

for Denso ECU with 93C56 memory and 29F200 flash.
The car must have 4C or 4D key.
39. TMS 374 – for Citroen, for Peugeot, for Renault for Citroen, for Peugeot, for Renault

Use: for Citroen, for Peugeot – ECU with TMS374 processor
Sagem SL96
Magnetti Marelli 1AP20, 1AP40, 1AP41, 1AP43, 1AP80, 1AP81, 1AP83, 1AP9
for Renault – ECU with TMS374 processor:
for Siemens Fenix 5
Sagem Safir 1
Sagem Safir 2
for Volvo – ECU with TMS374 processor
Siemens Fenix 5
(for Volvo V40/S40 / 1.8 i / 1996-1999/ ECU S113727100C_VOLVO /30850998-01)

40. For Yamaha

Use: for Yamaha motorbikes and scooters from 2004 to 2010.
Example models: YZF R1, YZF R6, FZ6 N, FZ6 S, T-MAX, X-MAX, V-MAX.

Seat occupancy sensor programs

1. For BMW
Europe from 2007 to 2010 year without installed child seat.
Models: E60, E63, E64, E65, E70, E71, E81, E90, E92, E93
for BMW from 1997 to 2007 without installed child seat
Models from 1997 to 2003: E31, E36, E38, E39, E46, E53
Models from 2003 to 2007: E60, E63, E65, E87, E90
for BMW from 1997 to 2007 with installed child seat
Models from 1997 to 2003: E31, E36, E38, E39, E46, E53
Models from 2003 to 2007: E60, E63, E65, E87, E90

2. For Fiat
for FIAT STILO without installed child seat.
for FIAT STILO with installed child seat.
3. For Mercedes
Without installed child seat:
Models: E-class W211 (2002-2004), S-class W220 (2003-2005), A-class W168, C-class W202, Vito W638, ML, E-class W210, Vito W639, ML W163, A-class W168, S-class W220, C-class W203, CLK W209, Vaneo, E-class W210
With installed child seat: E-class W211 (2002-2004), S-class W220 (2003-2005), A-class W168, C-class, W202, Vito W638, ML, E-class W210, E-class W210, Vito W639, ML W163, A-class W168, S-class W220, C-class W203, CLK W209, Vaneo
for Mercedes from 2004 to 2011 year
Models: E-class W211 2004 do 2007 Temic, SL W230 modele z 2004, SLK W171 2004 do 2011
Mercedes from 2003 to 2010 year
Models: E-class W211 from 2003 to 2007, Bosch contoller, C-class W203 from 2006 to 2007, CLS W219 from 2005 to 2010, CLK W209 from 2006 to 2009, S-class W220 from 2002 to 2005, S-class W221 year 2006 only

4. For Mini Cooper
for Mini Cooper 2002-2005 year without installed child seat.
for Mini Cooper 2002-2005 year with installed child seat.

5. For Mazda
Without installed child seat.:
Models: Premacy, MX-5, 626, 323, 6
With installed child seat:
Models: Premacy, MX-5, 626, 323, 6

For Tacho programs

1. for Audi Q7 and A6
2. for Citroen C4 Picasso
3. for EMF Display
4. for Renault Kangoo 3 Display
5. for Renault Scenc II, Espace IV Tacho
6. for Renault Scenic Full
7. for Renault Scenic III + Navi
8. for WV Passat B6
